Product Introduction of the 180kW DC Fast Charger
The 180 KW DC fast chargers are a significant development in the field of electric vehicle charging infrastructure. These chargers are capable of delivering high-power charging to electric vehicles, allowing them to recharge their batteries quickly and efficiently. This180 kW DC fast chargers are capable of providing up to 120 miles of range in just 15 minutes of charging time, depending on the specific electric vehicle being charged.
Specification of 180kW DC Fast Charger
| Name | 180kW DC Fast Charger |
| Input Power Factor | ＞0.99 |
| Input Total Harmonic Current | ＜5%（Rated Input） |
| Output DC voltage range | DC 150V-1000V |
| Max DC output current | 600A@300V/ 360A@500V/ 180A@1000V Each charging cable's max output current is 200A/CCS (optional 350A), 250A/GBT, 125A/CHAdeMO |
| Max DC output power | 180kW |
| Max system efficiency | >95.0%（Rated input and output） |
| Ambient temperature | -20 ~ +70°C , full power output below 45℃，Power derating 5%/ ℃ above 45℃ |
| Protection Class | IP55 |
Features of 180kW DC Fast Charger
● The 180kW DC Fast Charging solutions provide up to 180kW (up to 200A) continuous DC Fast Charging via CCS2 and can charge two EVs simultaneously at 90kW each.
● Charging Speed – 180 kW (1200km of range per hour of charge)
● 60kW, 90 kW, 120 kW,180 kW Versions available
● Compatible with all-electric vehicles with DC Capabilities
● Dynamic energy management to minimize charging time.
● Simultaneous charging of 2 e-cars
● 180kW (max) HV DC output power
● CCS or CHAdeMO or GBT multi-connectors can choose
● 2 x 90kW Simultaneous HV DC output: 200-920VDC- Can charge two EV’s at once
● Standard cable length 5m (upgrade to 7.5m or 10m available)
● 7” daylight readable LCD touch screen
● Support of OCPP interface
● Modules and can be upgraded and retrofitted.
Production Details of 180kW DC Fast Charger
FAQ
Q: Can your electric vehicle charging stations save me money?
A: Grasen EV Chargers offer valuable savings as well as smart technology such as “smart charging” which allows you to schedule specific times for your charger to turn on and off. This can help you save energy and money.
Q: How long is the lead time?
A: The lead time is 30-45 working days, it depends on the quantity and production schedule.
Q: What payment method does Grasen DC EV charger support?
A: RFID card, mobile APP, or POS.
Q: What is your warranty for EV chargers?
A: Generally 2 years. If you have special requirements please contact our customer service.
Q: Can you print our logo on the products? Can the color of the plug and cable be customized according to our requirements?
A: We support OEM and ODM service, but there will be a MOQ for custom design.
| Name | 180kW DC Fast Charger |
| Input Power Factor | ＞0.99 |
| Input Total Harmonic Current | ＜5%（Rated Input） |
| Output DC voltage range | DC 150V-1000V |
| Max DC output current | 600A@300V/ 360A@500V/ 180A@1000V Each charging cable's max output current is 200A/CCS (optional 350A), 250A/GBT, 125A/CHAdeMO |
| Max DC output power | 180kW |
| Max system efficiency | >95.0%（Rated input and output） |
| Ambient temperature | -20 ~ +70°C , full power output below 45℃，Power derating 5%/ ℃ above 45℃ |
| Protection Class | IP55 |
-- Marcus Groll，A Charging Station Owner in UKRAINE
Start your EV charging station businesses with Grasen. For a no-obligation quote, hit the button below, fill in your details, and we’ll get back to you.
